Ductile Iron Pipes & Fittings

Supplier: Thaqat Al Juzeira Trading Est.
Origin: Indian Make, Saudi Make

Product Overview

Ductile Iron (DI) Pipes and Fittings are robust, versatile, and designed for high-performance applications in water and wastewater systems. These products comply with the Saudi Standards, Metrology, and Quality Organization (SASO) and other relevant international standards like ISO 2531 and EN 545, ensuring reliability and safety.

Our DI pipes are available in flanged, socketed, and spigot-end types, while fittings come in standard designs or customized configurations fabricated by our in-house department to meet client-specific requirements.

Technical Specifications

Standards Compliance

SASO standards
ISO 2531: Ductile Iron Pipes
EN 545: Water Supply
ISO 4179: Coatings
AWWA C151/A21.51 (on demand)

Available Sizes

Pipes: DN 80 to DN 2600 mm

Fittings: DN 80 to DN 2000 mm

Classifications

Wall Thickness: K7, K8, K9, K12

Pressure Class: PN10, PN16, PN25

Material

High-strength ductile cast iron with high elongation properties for superior ductility and impact resistance.

Coatings

Internal: Cement mortar lining (ISO 4179)

External: Zinc coating, bituminous paint, or epoxy resin coating

Joint Types

Push-on (socketed) joints and Flanged joints for leak-proof, reliable connections.

Key Features

High Strength & Ductility

Superior to gray cast iron, enabling resistance to stress and impact in demanding applications.

Corrosion Resistance

Internal and external coatings protect against corrosion in aggressive environments.

Leak-Proof Joints

Push-on and flanged joints ensure reliable and leak-proof connections.

Ease of Installation

Lightweight design reduces handling and installation time compared to traditional materials.

Customization

Flexible production to create bespoke fittings for specific project requirements.

Long Service Life

Minimal maintenance required with operational life exceeding 50+ years.

Applications

Water Supply Systems: Potable water pipelines, municipal and industrial water distribution networks.
Sewage and Drainage Systems: Wastewater transport networks, sewage treatment plant pipelines.
Irrigation: Agricultural water delivery systems, pressurized irrigation lines.
Fire Protection Systems: Hydrant systems and sprinkler pipelines for reliable fire suppression.
Industrial Piping: Chemical transport systems (subject to lining and coating requirements).
